All Flex Flexible Circuits is a high quality, customer-driven manufacturing company providing quick-turn
prototype, and high volume manufacturing of flexible circuitry and flexible heaters. We offer a wide
variety of materials and services to meet the requirements of the unique design and application.

PRODUCT OFFERING
 Flexible circuits and flexible heaters
 Single and double sided flex circuits
 All Flex trademarked, Maxi-Flex™, extended
length circuits, 8 feet +
 Multi-layer flex up to 8 layers
 Selective rigid flex up to 8 layers
 Custom and standard, stocked polyimide and
silicone rubber heaters
 Ultra fine line technology with 50 micron line/
space capability
 Unsupported copper tabs
 Thick copper/power distribution circuits up to
20 mils
 Alternative metal alloys
 Polyimide and polyester dielectric films
 Adhesive and adhesiveless materials
 Full offering of RoHS surface coatings
 High speed, fine pitch through-hole and SMT
component assembly down to 0201
 Microscope soldering/assembly
 Digitally controlled nomenclature printing and
QR Code
COMPLIANCE/CERTIFICATIONS
 ISO 9001:2008 Certified
 AS9100C Certified
 MIL-P-50884E Qualified
 ITAR\JCP Registered
 UL Recognized
 IPC Active Member
 RoHS Compliant
SERVICE OFFERING
 Fast quoting (typically within 24 hours)
 Standard delivery lead time of 2-3 weeks, expediting
available
 Full circuit design from schematic
 Rigid PCB design conversion to flex
 Reverse engineering of existing products into
flexible circuitry designs
 Improved design refinement (‘flexizing’) to
optimize features for flexible circuit performance
and reliability
 Heater design to defined thermal output
 AOI (automated optical inspection)
 Flying probe, bed of nails and piece part ET test
 Consultation/design assistance
 Jumpstart program used to continuously improve
new part introduction process (NPIP)
 Online design course, self-paced:
www.designingflexiblecircuits.com
